1586534-2 by te connectivity / amp brand
Image is representational - see mfr. specs

1586534-2

TE Connectivity / AMP Brand

04P CMNL HDR ASSY SHORT LF ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1586534-2 is a 4-position PCB pin header designed for use in 5.0 mm Power Key Connector (5.0 PKC) wire-to-board applications. This vertical socket header features a pre-tin duplex finish with gold plating in the mating area and matte tin on the solder tail, with a positive lock mechanism for secure connections. The connector has a 5.0 mm contact centerline and a compact mated height of 19.4 mm, with an A dimension of 0.915 inches (23.24 mm). It is designed for use with 0.062 inch (1.57 mm) thick PC boards and mates with socket housing part number 1-480722-0. Common applications include power circuits in home appliances, particularly gas appliances, where reliable power connections are essential.

Product Highlights:

  • Header
  • Contact Diameter = 2.13 mm
  • Number of Circuits = 4
  • 5.08 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 15865342

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1586534-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Number of Contacts:
4
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
13/Contact A
Operating Temperature:
-30 to 105 °C

IN STOCK: 8,213

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$3.274
10
$2.977
50
$2.668
100
$2.657
250
$2.565
500
$2.503
1,000
$2.493
3,000
$2.441
6,000 +
$2.421
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

1-480722-0

04P CMNL PLUG HSG W/LCK NATL
