1658620-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1658620-1

TE Connectivity / AMP Brand

A 10-position, military-polarized Novo receptacle for terminating .050 inch pitch ribbon cable to a .100 x .100 inch grid. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1658620-1 is a 10-position, preassembled Novo receptacle connector with military-style polarization. It features two rows of tuning-fork contacts on .100 x .100 inch centers, designed for the mass termination of 26-28 AWG ribbon cable. The contacts have duplex plating, with .000015 inches of gold or gold flash over palladium-nickel on the mating end and tin on the termination end, all over a nickel underplate. This connector mates with .025 inch square or round posts, providing a reliable and cost-effective wire-to-board interconnect solution for various electronic equipment.

Product Highlights:

  • Connector Type = NOVO
  • Number of Positions = 10
  • Receptacle
  • Mating Polarization Method = Military
  • With Mating Polarization

Search Keywords: 16586201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658620-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
144
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

IN STOCK: 6,768

Can Ship immediately

Minimum Order Quantity: 144

Multiple: 144

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
144
$0.915
288
$0.870
576
$0.788
1,008
$0.736
2,592
$0.731
5,040
$0.725
7,632
$0.724
10,080 +
$0.722
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
