1658645-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1658645-1

TE Connectivity / AMP Brand

D Sub Connector Housing - 9 Ways - D Sub - DE - AMPLIMITE HDP-20 Series - Plug - Steel Body. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1658645-1 is a 9-position Basic Shielding Hardware Plug Kit with tin-plated steel shell and tin over copper steel shield. The Amplimite HDP-20 series connector housing is made of black GF nylon with PBT GF insert. Plug accepts 20-pin contact.

Product Highlights:

  • Connector Kit
  • Product Series = HDP-20 (Crimp Snap)
  • Number of Positions = 9
  • Shielded
  • Plug

Search Keywords: 16586451

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658645-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
9
Contact Plating:
N/A
Operating Temperature:
-55 to 105 °C

IN STOCK: 2,565

Can Ship immediately

On Order: 6,000   can ship 1/27/27

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 39 Weeks

Price (USD)

Qty
Unit Price
100
$1.77
300
$1.47
500
$1.44
1,000
$1.42
2,500
$1.39
5,000
$1.36
7,500
$1.34
10,000 +
$1.33
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

5748536-1

KIT,RCPT,9P,HDP-20,SHLD HDWRE

205203-8

CRIMP SNAP RCPT ASSY,SIZE 1

1658654-1

KIT,HDP-20,ENCLSUR,RCPT,SIZE 1

1658646-1

Receptacle for Female Contacts Housing D-Sub Connector 9 Position

1658643-1

Receptacle for Female Contacts Housing D-Sub Connector 9 Position

164531-4

9P.HDP20 REC.ASSY.

205203-3

CRIMP SNAP RCPT ASSY,SIZE 1
