1658691-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications

1658691-1

TE Connectivity / AMP Brand

D Sub Connector Housing - 15 Positions - D Sub - 1 - AMPLIMITE HDP-22 Series - Plug - Steel Body. ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Using the high density d-sub 1658691-1 DVI connector from TE Connectivity is fast and easy for communicating between serial connections in your circuit. It has a straight body orientation. This 3-row connector has a single port. 1658691-1 is housed in nylon. Its 15 terminals use the crimp termination method. This product is 30.81 mm long, 12.55 mm tall and 18.21 mm deep.

Product Highlights:

  • Product Series = HDP-22 (Crimp Snap)
  • 15 Positions
  • Without Enclosure
  • Housing Gender = Plug
  • Without Contacts

Search Keywords: 16586911

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658691-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
BOX
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
15
Contact Plating:
N/A
Operating Temperature:
N/A

IN STOCK: 1

Can Ship immediately

Buy all 1 in-stock or the regular minimum order quantity of 5

Stock lot only: 1

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$11.817
5
$10.743
25
$9.641
50
$8.992
100
$8.322
400
$8.219
800
$8.199
1,200 +
$8.178
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
