166293-1 by te connectivity / amp brand

166293-1

TE Connectivity / AMP Brand

LP HD20 COSI PIN CONTACT DF; 24-20 AWG ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / AMP Brand part 166293-1 is a high-quality, durable LP HD20 COSI PIN CONTACT DF. It is designed to securely connect wires of 24-20 AWG, ensuring reliable electrical connections in various applications. The pin contact features a compact design and is compatible with the HD20 series connectors. It guarantees efficient transmission of signals and power, making it ideal for use in demanding environments. Trustworthy and efficient, this pin contact meets the industry standards for exceptional performance and longevity.

Product Highlights:

  • Contact
  • Product Series = HDP-20 (Crimp Snap)
  • Pin
  • Wire Termination Type = Crimp
  • Wire Insulation Diameter = 1.52 mm

Search Keywords: 1662931

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
166293-1
RoHS:
Yes
HTS:
8536698000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Reel
Contact Type:
Signal
Gender:
Pin
Contact Size:
20
Wire Size:
20-24 AWG
Contact Material:
Brass
Contact Plating:
Gold over Nickel
Maximum Current Rating:
3.7 A
Termination Method:
Crimp

IN STOCK: 50,733

Can Ship immediately

Minimum Order: 100

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
100
$0.3373
1,000
$0.1934
3,000
$0.1834
5,000
$0.1809
8,000
$0.1758
25,000
$0.1749
50,000
$0.1741
100,000 +
$0.1732
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1579007-9

Extraction Tool for AMPLIMITE HD-20

91503-1

Hand Crimper Tool D-Sub Contacts

58448-2

PRO CR. ASSY AMPLIMITE IS 9357

58448-3

PRO-CRIMPER DIE

91285-1

Insertion Tool, Insertion/Extraction Tool, Amplimite HDP-20, HDP-22 Series Contacts

Show 3 More
