170330-2 by te connectivity / amp brand
Image is representational - see mfr. specs

170330-2

TE Connectivity / AMP Brand

PL 187 RECEPTACLE 24-20 AWG NPPHBZ ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

170330-2 is an insulated receptacle housing for TE Connectivity's Positive Lock FASTON terminals, engineered to provide secure retention and ease of assembly. The housing is constructed from 6/6 Nylon material with UL 94 V2 flame rating, available in natural color, and features an integrally designed depressor mechanism that allows manual or automatic deflection for terminal removal. The receptacle locks onto mating tabs containing holes with reduced insertion force and provides a "snap" action confirmation of proper mating. This design enhances safety by preventing accidental disconnection of terminals and reducing the risk of exposed live parts or circuit disruption. The housing is recognized under UL Component Program File Nos. E66717 and E28476, and certified by Canadian Standards Association (File No. LR7189A), making it suitable for automotive and industrial applications requiring reliable electrical connections in confined spaces.

Search Keywords: 1703302

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
170330-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Bag
Contact Type:
Stamped Signal
Gender:
SKT
Contact Size:
N/A
Wire Size:
20-24 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Nickel
Maximum Current Rating:
N/A
Termination Method:
Crimp

IN STOCK: 5,051

Ships today, if you order in

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
500
$0.3670
1,000
$0.3661
2,500
$0.3375
5,000
$0.3248
7,500
$0.3149
10,000
$0.2716
15,000
$0.2649
25,000 +
$0.2642
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

169994-1

POS.LOCK H.T.4,8

2063760-1

CCII 187 POSITIVE LOCK REC 24-20 ASSY

724659-1

Extraction Tool for POSITIVE LOCK 4.8 [.187] Mk II Receptacle

724659-5

Extraction Tool for POSITIVE LOCK Mk II

Show 2 More
