172344-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

172344-1

MINI UNIVERSAL MATE-N-LOK CAP HOUSING 3P ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

172344-1 is a 3-circuit free-hanging cap housing connector from the Mini-Universal MATE-N-LOK connector series. This connector is manufactured from UL94V-2 rated nylon in natural color, providing flame retardant properties. The housing features dimensions of A=0.551 inch (9.80 mm), B=0.591 inch (10.79 mm), C=0.654 inch (12.39 mm), and D=0.630 inch (11.78 mm). It is designed for wire-to-wire applications and mates with corresponding plug housings. This RoHS compliant connector is commonly used in electronic assemblies requiring reliable signal connections with a double lock mechanism for secure contact retention.

Product Highlights:

  • Housing
  • Mini-Universal MATE-N-LOK
  • Number of Circuits = 3
  • 4.14 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 1723441

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
172344-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Package Type:
BAG
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
3
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
-20 to 105 °C

IN STOCK: 33,776

Ships today, if you order in

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
500
$0.2797
1,000
$0.2730
2,500
$0.2663
5,000
$0.2656
7,500
$0.2648
10,000
$0.2633
15,000
$0.2627
25,000 +
$0.2593
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes
