1-747943-7 by te connectivity / amp brand

1-747943-7

TE Connectivity / AMP Brand

KIT,RCPT,9P,HDE,SHLD ENCLSRE ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 1-747943-7 is a comprehensive and high-quality kit designed for the assembly and installation of a 9-pin receptacle with a heavy-duty shielded enclosure. This kit is specifically engineered to ensure reliable and secure connections, while protecting against electromagnetic interference.The kit includes all the necessary components to quickly and effectively install the receptacle, including a detailed instruction manual. The heavy-duty shielded enclosure offers an added layer of protection, making it ideal for use in demanding environments or applications that require robust shielding.TE Connectivity / AMP Brand is a trusted and renowned manufacturer known for their commitment to excellence and reliable solutions. With the 1-747943-7 kit, you can be confident in the durability and performance of your connections, ensuring a smooth and efficient operation.

Product Highlights:

  • Connector Kit
  • Product Series = HDE-20 (IDC)
  • Number of Positions = 9
  • Shielded
  • Receptacle

Search Keywords: 17479437

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-747943-7
RoHS:
Yes
HTS:
8536698000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 626

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
5
$10.939
25
$10.671
50
$10.516
100
$10.413
250
$9.878
500
$9.208
1,000 +
$8.013
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
