1757819-7 by te connectivity / amp brand
Image is representational - see mfr. specs

1757819-7

TE Connectivity / AMP Brand

AMPLIMITE,ASY,PLUG,STD,109,ZN,2,CT ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

M24308/4-2Z is a military-specification circular connector plug designed for reliable interconnection in demanding applications. The connector features a steel shell (per ASTM A 109) with zinc plating (minimum 0.0002 inches thick per ASTM-B-633) and yellow chromate finish for corrosion resistance. It utilizes size 22 pin contacts made from copper alloy with gold plating over nickel, and an insert assembly constructed from polyphenylene sulfide (PPS) or glass-filled polyester material. The connector mates with any receptacle connector having the same insert arrangement, making it suitable for military, aerospace, and industrial applications requiring robust and dependable connections.

Product Highlights:

  • Connector
  • Product Series = 109
  • Density = Standard
  • Terminate To Wire
  • Number of Positions = 15

Search Keywords: 17578197

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1757819-7
Alias/AKA:
M24308/4-2Z
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
2
Number of Contacts:
15
Shell Plating Material:
Zinc/Steel
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C

IN STOCK: 466

Can Ship immediately

Factory Lead-Time 31 Weeks

Price (USD)

Qty
Unit Price
1
$13.60
50
$13.38
100
$12.86
250 +
$12.62
