Image is representational - see mfr. specs

1761607-5

TE Connectivity / AMP Brand

The 1761607-5 is a 14-position, right-angle PCB mount, low-profile pin header with military and center polarization and long ejection latches. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1761607-5 is a 14-position, right-angle, low-profile pin header designed for ribbon cable connections. It features military and center polarization with die-cast long ejection latches, making it suitable for mating with receptacles that have a strain relief. The housing is made from black, UL 94V-0 rated glass-filled PBT, and the phosphor bronze posts are duplex plated with gold over palladium-nickel on the mating surfaces and tin on the solder area. This header is rated for a maximum current of 1A per contact, an operating voltage of 250 VAC, and can operate in temperatures from -65°C to +105°C. It is designed for reliable board-to-cable interconnections in various electronic equipment.

Product Highlights:

  • Connector Type = Pin Header
  • Low Profile
  • Number of Positions = 14
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Right Angle

Search Keywords: 17616075

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1761607-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Tube
Type:
Ejector Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
14
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 480

Can Ship immediately

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
20
$5.78
60
$5.72
100
$5.07
260
$5.05
500
$4.50
1,000
$4.28
2,500
$4.27
5,000 +
$4.26
Suppliers Standard Package
