1761681-9 by te connectivity / amp brand
Image is representational - see mfr. specs

1761681-9

TE Connectivity / AMP Brand

IDC LOW PRO HDR 26P VERT HT BLACK ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1761681-9 is a 26-position vertical header assembly connector designed for PCB mounting applications. It features a PCT housing rated UL94V-0 in black color with phosphor bronze posts that have gold plating (0.00038 mm min) on the mating area, tin plating (0.00254 mm min) on the solder end, and nickel underplating (0.00127 mm min) on the entire post. The connector has a 2.54 mm (0.100 inch) pitch spacing and overall dimensions of approximately 38.10 mm (1.500 inch) in length (dimension B) and 40.64 mm (1.600 inch) in dimension A. This header assembly is suitable for general-purpose electronic interconnect applications requiring reliable vertical board-to-board or wire-to-board connections.

Product Highlights:

  • Preloaded
  • Housing Gender = Header - Pin
  • Header Type = Pin Header
  • AMP-LATCH Product Line
  • Low Profile

Search Keywords: 17616819

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1761681-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Pack
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
26
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 6,326

Can Ship immediately

Minimum Order Quantity: 50

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
50
$2.44
100
$2.34
250
$2.21
500
$2.12
1,000
$2.03
2,500
$1.91
5,000
$1.68
7,500 +
$1.63
Suppliers Standard Package
