1-770974-1 by te connectivity / amp brand

1-770974-1

TE Connectivity / AMP Brand

16P MINI UMNL R/A HDR ASSY LF ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 1-770974-1 is a 16-pin, right-angle header assembly designed for use in miniature universal mate n' lock connectors. This assembly offers a low-profile design and is lead-free, making it suitable for environmentally conscious applications. With its compact size and efficient design, it provides a reliable and secure connection for your electronic projects.

Product Highlights:

  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 16
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout

Search Keywords: 17709741

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770974-1
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
16
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A

IN STOCK: 120

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
5
$18.437
25
$17.228
50
$17.151
200
$15.053
400
$14.915
600
$14.839
1,000 +
$14.761
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Product Changes

Accessories

770583-1

16P MINI UMNL PLUG HSG

794206-1

16P MINI UMNL2 PLUG HSG UL94V0
