1-776228-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1-776228-1

TE Connectivity / AMP Brand

Rectangular Power Connector - 23 Contacts - AMPSEAL Series - PCB Mount - Through Hole - 2 mm - Header. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-776228-1 is AMPSEAL series Plug Assembly Housing for female terminals made up of glass reinforced PBT. AMPSEAL automotive connectors provide rugged reliability, easy use and superior environmental sealing.

Product Highlights:

  • Header Assembly
  • Number of Positions = 23
  • Terminate To Panel, Terminate To Printed Circuit Board
  • Vertical Mount Angle
  • With Gasket

Search Keywords: 17762281

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-776228-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tray
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
23
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
17/Contact A
Operating Temperature:
-40 to 125 °C

IN STOCK: 190

Ships today, if you order in

On Order: 1,600   can ship 6/22/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$9.16
40
$4.90
80
$4.83
120
$4.73
280
$4.71
520
$4.67
1,000 +
$4.66
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
