1-794065-1 by te connectivity / amp brand

1-794065-1

TE Connectivity / AMP Brand

Wire-To-Board Connector - 4.14 mm - 8 Contacts - Header - Mini Universal MATE-N-LOK Series. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-794065-1 power connector from TE Connectivity is perfect for powering your circuit because it comes with the least amount of losses. This HDR connector's 8 contacts that are made out of brass and plated with gold over nickel. This connector has a single port. It has a header type gender. It has a straight body orientation. Its pitch is 4.14 mm. It has a maximum voltage rating of 600 VAC. 1-794065-1 is housed in nylon. This device has a maximum current rating of 9.5 A/contact. This product is 14.25 mm tall. Its 8 terminals use the solder termination method.

Product Highlights:

  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 8
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout

Search Keywords: 17940651

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-794065-1
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
8
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A

IN STOCK: 3,885

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
10
$4.181
200
$2.834
400
$2.788
600 +
$2.756
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Product Changes

Accessories

770579-1

08P MINI UMNL PLUG HSG

794192-1

Connector Housing - Mini Universal Mate-N-Lok 2 Series - Plug - 8 Ways - 4.14 mm.
