1-794071-0

22P MINI UMNL HDR W/DH SN LF ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

1-794071-0 is a 22-circuit dual-row vertical pin header connector designed for Mini-Universal MATE-N-LOK 2 mating applications. The connector features an A dimension of 1.854 inches (47.09 mm) and is available with tin or duplex plating finishes. Tin finish is plated with a minimum of 0.000150 inches (0.00381 mm) tin over 0.000050 inches (0.00127 mm) nickel underplate on the entire contact, while duplex finish includes 0.000030 inches (0.000762 mm) minimum gold in the mating area and matte tin on the solder tail end over the same nickel underplate. This connector is RoHS compliant and is commonly used in high-density interconnect applications requiring reliable board-to-board or board-to-cable connections with multiple signal paths.

Product Highlights:

  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 22
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout

Search Keywords: 17940710

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-794071-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
BAG
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
22
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A

IN STOCK: 0

MOQ for out of Stock Qty: 100

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
100
$4.80
200
$3.59
300
$3.36
400 +
$3.30
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes

Accessories

794212-1

22P MINI UMNL2 PLUG HSG UL94V0

770586-1

22P MINI UMNL PLUG HSG
