1-794615-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-794615-0

PANEL MT DBL ROW HSG 10 POS ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

1-794615-0 is a Micro MATE-N-LOK connector housing plug from TE Connectivity's 3mm connector system, designed for wire-to-wire and wire-to-board connections. This VDE approved connector features a double row configuration with 10 positions and is designed for free hanging applications. The connector system operates on a 3.0mm pitch centerline spacing with a maximum current rating of 5 Amps per line and is rated for 250 Volts AC/DC. It is compatible with pin and receptacle contacts including x-794608-x, x-794609-x, x-794612-x, and x-794613-x terminals, and mates with 3-794617-x receptacle housings. This connector is suitable for applications requiring reliable wire-to-wire connections with VDE certification.

Product Highlights:

  • Housing
  • Housing Type = Plug
  • Number of Positions = 10
  • Number of Rows = Dual
  • Mount Type = Panel Mount

Search Keywords: 17946150

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-794615-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BAG
Mounting:
Panel Mount
Body Orientation:
Straight
Gender:
PL
Number of Contacts:
10
Maximum Voltage Rating:
250,250 VDC|VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C

IN STOCK: 26,057

Can Ship immediately

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$0.6639
500
$0.6036
1,000
$0.5696
2,500
$0.5315
5,000
$0.5305
7,500
$0.5294
10,000
$0.5274
15,000
$0.5263
25,000 +
$0.5253
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

1-794617-0

Connector Housing - Micro MATE-N-LOK Series - Receptacle - 10 Ways - 3 mm - Micro MATE-N-L ...
