1-796387-2

Name: 1-796387-2
Brand: Te Connectivity Amp Brand
SKU: 10193487
Price: 4791 USD
Availability: OutOfStock

CPC PSTD RCPT,23-24,R/A LF ...

View Datasheet Ask the Datasheet

RoHS Compliant

TRAY Packaging

Certificate of Compliance

DESCRIPTION

1-796387-2 is a square flange receptacle assembly designed for the 23-37 shell size AMP circular plastic connector series, configured as standard sex to accept pin contacts. This receptacle features mounting holes for panel installation and is constructed from UL 94V-0 rated, heat-resistant thermoplastic material with a metal-shell housing. The connector operates over a temperature range of -40°C to +105°C and includes built-in pin protection, polarized keying (Key Style A with 5 locating keys), and quick connect/disconnect capability with thread-assist coupling. The contact body finish is specified as Code B, and it mates with plug part number 206150-1, making it suitable for commercial signal and power applications requiring reliable, lightweight circular connectors with positive detent coupling and proper mating protection.

Product Highlights:

Preloaded
24 Positions
24 Signal Positions
0 Power Positions
Connector Style = Receptacle

Potential Applications:

Search Keywords: 17963872

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-796387-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694040

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
