1-796403-2

Name: 1-796403-2
Brand: Te Connectivity Amp Brand
SKU: 10193499
Price: 50.86 USD
Availability: InStock

The 1-796403-2 is a CPC Series 1 right-angle, posted square flange receptacle with an 11-4 standard sex contact arrangement and .025 inch square solder tails. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

TRAY Packaging

Certificate of Compliance

DESCRIPTION

The 1-796403-2 is a CPC Series 1 right-angle, posted square flange receptacle designed for printed circuit board applications. It features an 11-4 contact arrangement with posted pin contacts and 4-40 threaded inserts for secure panel mounting. The contacts have a gold finish on the mating end for reliable connection, and the .025 inch square solder tails facilitate PCB termination. The housing is made from a UL 94V-0 rated black thermoplastic, ensuring heat resistance and self-extinguishing properties within an operating temperature range of -40°C to +105°C. This connector is polarized with a standard 5-key configuration and is suitable for commercial signal and power applications requiring a robust, right-angle board-to-cable connection.

Product Highlights:

Connector
Number of Positions = 4
Receptacle
Pin
Preloaded

Potential Applications:

Search Keywords: 17964032

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-796403-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694040

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
