184340-1

PLUG ASSY,2X2,CPA,W/O SLOT,CKT4 BLKD ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

184340-1 is a sealed sensor connector housing component from TE Connectivity's SSC (Sealed Sensor Connector) System, designed for automotive under hood environments. The SSC System features glass-filled PBT housing material for high temperature applications, with a wire size range of 0.30–2.0 mm² (22–14 AWG) and 5 mm centerline spacing. The system provides robust sealing conforming to IEC 529 IP 65/67 standard with 7 Psi initial sealing pressure, and operates over a temperature range of -40°C to +125°C for PBT housings. It includes Terminal Position Assurance (TPA) and a damage-protected internal silicone seal interface. This connector system is ideal for powertrain systems, safety and security systems, and other automotive applications requiring waterproof and high-temperature performance.

Product Highlights:

  • Housing
  • Housing Type = Plug
  • With Connector Position Assurance
  • Number of Positions = 4 (2x2)
  • Color = Black

Search Keywords: 1843401

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
184340-1
Unit of Measure:
Per Each
RoHS:
No
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
PL
Number of Contacts:
4
Maximum Voltage Rating:
N/A
Maximum Current Rating:
10/Contact A
Operating Temperature:
-40 to 125 °C

IN STOCK: 4,281

Ships today, if you order in

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 250

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
10
$5.24
50
$4.58
100
$4.23
250
$3.69
500
$3.51
750
$3.50
1,000 +
$3.04
