1-967628-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-967628-1

FLA-ST-GEH 2.8 15P ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

1-967628-1 is an AMP MCP 2.8 mm unsealed tab housing connector designed for the AMP MCP Interconnection System used in automotive applications. This 15-position connector features Coding A keying and is constructed with PA 66 GF13 housing material, supporting wire sizes up to 2.5 mm² FLR maximum. The connector is part of the AMP MCP system which provides high reliability for long-term use across powertrain systems, safety and security systems, convenience features, driver information displays, and body and chassis systems. The tab housing mates with receptacle housings and includes optional secondary locking capability for enhanced connection security. This connector is widely used in motor vehicle electrical and electronic applications where robust, reliable interconnection is required.

Product Highlights:

  • Tab Housing
  • Connector Type = Junior Power Timer
  • Tab Fit = 2.79 x 0.81 mm
  • Number of Positions = 15
  • Housing Color = Purple

Search Keywords: 19676281

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-967628-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MA
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
800
Package Type:
BAG
Mounting:
N/A
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
15
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A

IN STOCK: 3,865

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
25
$1.68
250
$1.41
800
$1.30
1,600
$1.28
3,200
$1.27
5,600
$1.26
8,000
$1.25
10,400 +
$1.24
Supplier's Standard Package
