206061-3

Name: 206061-3
Brand: Te Connectivity Amp Brand
SKU: 10316169
Price: 201.6 USD
Availability: InStock

CPC RECPT,SZ 11-4,SMALL PACK ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BOX Packaging

End of Life: Final orders must be placed by 04/01/2027

DESCRIPTION

The 206061-3 is a receptacle housing connector manufactured by TE Connectivity/AMP brand, specifically designed as a small pack variant for standard sex shell size 11 CPC applications. This connector features a nylon black housing with peripheral seal bonded in place and is engineered to accept four Multimate pin contacts with cavity identification on both front and rear faces. The housing dimensions include an outer diameter of 21.34 mm (0.840 inches) with a panel cutout of 17.45±0.25 mm diameter, and mounting provisions with 3.18 mm diameter holes. The connector utilizes a 5/8–24 UNEF–2A thread specification and accommodates a maximum panel thickness of 3.18 mm. This receptacle housing is commonly used in telecommunications, industrial control systems, and power distribution applications where reliable multi-pin connections are required.

Product Highlights:

Potential Applications:

Search Keywords: 2060613

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

206061-3

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99
