2141576-1

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

2141576-1

RoHS:

Yes

HTS:

8538906000

COO:

DE

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1000

Package Type:

Carton

Serviceable:

Yes

Body Material:

PBT GF

Connector & Housing Type:

Housing for female terminals

Operating Temperature (Max):

100 °C, 105 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 158 °F, 167 °F, 176 °F

Connector Position Assurance Capable:

No

Primary Product Color:

Black

Operating Voltage:

12 VDC

Terminal Position Assurance:

Yes

Nominal Voltage Architecture:

12 V

Cable Exit Angle:

180 °

Length:

1.303 in, 33.1 mm

Primary Locking Feature:

On the Terminal

Height:

.646 in, 16.4 mm

Width:

.583 in, 14.8 mm

Operating Temperature Range:

-40 – 105 °C, -40 – 221 °F

Centerline (Pitch):

.071 in, 1.8 mm

Packaging Method:

Box & Carton

Connector System:

Wire-to-Board , Wire-to-Device

Number of Positions:

32

Strain Relief:

No

Sealable:

No

Row-to-Row Spacing:

.232 in, 5.9 mm

Mounting Feature:

Without

Circuit Application:

Signal

Polarized:

Yes

Mating Tab Width:

.02 in, .5 mm

Hybrid Connector:

No

Number of Rows:

2
