2-1445094-6 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

2-1445094-6

Conn Power HDR 6 POS 3mm Solder ST Thru-Hole 6 Terminal 1 Port Box/Tray ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tray Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

2-1445094-6 is a single-row header connector from the Micro MATE-N-LOK 3 mm connector system designed for wire-to-board connections. The connector supports 2–12 positions with contacts on a 3 mm (0.118 inch) centerline spacing and accommodates wire sizes from 30–18 AWG (0.05–0.9 mm²) with insulation diameters up to 1.52 mm. It is available in both surface mount technology (SMT) and through-hole configurations with multiple board mount options including SMT hole metal, through-hole hold down, and plastic hold down features. The header features retention bumps on the solder tail and is compatible with 15 µm and 30 µm gold plating options, making it suitable for appliance and industrial applications requiring reliable wire-to-board interconnections.

Search Keywords: 214450946

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-1445094-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
154
Package Type:
Tray
Type:
Power3706
Body Orientation:
Straight3686
Mounting:
Through Hole3696
Gender:
HDR3690
Number of Contacts:
6
Termination Method:
Solder3705
Maximum Voltage Rating:
2503694VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 335

Ships today, if you order in

Minimum Order Quantity: 154

Multiple: 154

Price (USD)

Qty
Unit Price
154
$2.63
308
$2.58
616
$1.59
924
$1.26
1,232 +
$1.24
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models
