2-1761713-3 by te connectivity / amp brand
Image is representational - see mfr. specs

2-1761713-3

TE Connectivity / AMP Brand

IDC LOW PRO HDR 10P VERT SHT L ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

2-1761713-3 is a low-profile pin header connector designed for vertical PCB mounting with 10 positions arranged in a 2.54 x 2.54 mm centerline matrix. The connector features a 4-sided shrouded housing with short eject latches and center mating polarization, providing secure and polarized connections. The header incorporates phosphor bronze contacts with gold flash over palladium nickel plating for reliable mating, and solder tail posts measuring 4.11 mm in length with tin over nickel plating. The PBT housing is rated UL 94V-0 for flammability and is available in blue, with full RoHS/ELV compliance. This connector is suitable for ribbon cable and flat flex wire applications, offering wave solder capability up to 265°C for robust PCB assembly in industrial and consumer electronics.

Product Highlights:

  • With Contacts
  • Housing Gender = Header - Pin
  • Header Type = Pin Header
  • AMP-LATCH Product Line
  • Low Profile

Search Keywords: 217617133

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-1761713-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Pack
Type:
Ejector Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 370

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
50
$1.715
100
$1.702
250
$1.654
500
$1.628
1,000
$1.608
2,500
$1.600
5,000
$1.591
7,500 +
$1.584
Suppliers Standard Package
