228226-1 by te connectivity / amp brand
Image is representational - see mfr. specs

228226-1

TE Connectivity / AMP Brand

BNC BLKHD JACK ADAPTER GOLD ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

228226-1 is a BNC 50 Ohm bulkhead jack-jack adapter designed for RF coaxial connector applications. The adapter features a nickel-plated body with gold-plated center contact (Gold1 plating at 0.00127 mm thick) and polyethylene dielectric material for reliable signal transmission. Key dimensional specifications include a height (H) of 17.78 mm (700 mils) and length (L) of 36.07 mm (1420 mils), with a recommended panel cutout of 11/16 inch across flats and 20.32 mm across points. This bulkhead configuration is ideal for panel-mount applications in RF systems, telecommunications equipment, and test instrumentation where secure, shielded connections are required.

Product Highlights:

  • Adapter
  • Connector Type = BNC
  • Jack
  • Not Stacked
  • 1 Ports

Search Keywords: 2282261

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
228226-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
BNC Adapter
Impedance:
50 Ohm
Operating Frequency:
N/A
Gender:
RCP/RCP
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
36.07 x 24.38 mm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 383

Ships today, if you order in

Buy all 383 in-stock or the regular minimum order quantity of 500

Stock lot only: 383

Minimum Order Quantity: 500

Price (USD)

Qty
Unit Price
1
$6.220
500
$5.655
1,000
$4.851
2,500
$4.316
5,000 +
$3.595
