2-36150-1 by te connectivity / amp brand

2-36150-1

TE Connectivity / AMP Brand

TERM, RING, PIDG, 22-16, 6, T&R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 2-36150-1 is a high-quality TERM, RING, PIDG (Pre-Insulated Diamond Grip), designed for 22-16 AWG (American Wire Gauge) wires. This terminal features a secure connection with its ring shape, providing a reliable and durable electrical connection. It is supplied in a tape and reel (T&R) packaging, making it suitable for high-volume production. The 2-36150-1 is an excellent choice for various applications that require a compact and efficient wire termination solution.

Product Highlights:

  • Terminal Shape = Ring Tongue
  • Receptacle Style = Straight
  • Body Style = PIDG
  • Barrel Type = Closed Barrel
  • Wire/Cable Type = Regular Wire

Search Keywords: 2361501

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-36150-1
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
Reel
Type:
Ring Tongue Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
3.5 mm
Dimension:
17.07 x 5.54 mm
Wire Size:
16-22 AWG
Color:
Red
Operating Temperature:
105(Max) °C

IN STOCK: 50,286

Ships today, if you order in

Minimum Order: 5000

Multiple: 5000

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
5,000
$0.1688
10,000
$0.1658
25,000
$0.1650
50,000
$0.1642
100,000 +
$0.1634
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Accessories

47386

DAHT PG PIDG 26-16 ASSY

59824-1

Crimp Tool - Hand - AMP TETRA PIDG/PLASTI-GRIP/PIDG Faston 22-10AWG Terminals & Splices.

58433-3

Crimp Tool: PRO-CRIMPER III Mnl Crimp Tool Frame (354940-1) + Die Set for PIDG, PLASTI-GRI ...

58423-1

Tool Die Set For Splices and Terminals - 10 to 22 AWG.

169404

CERTI-LOK DIE

Show 3 More
