2-5499206-8 by te connectivity / amp brand
Image is representational - see mfr. specs

2-5499206-8

TE Connectivity / AMP Brand

A/L UNIV HDR 34P VERT LG LAT B ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2-5499206-8 is a universal header assembly connector featuring AMP-latch technology designed for secure and repeatable mating in electronic applications. This 40-position connector is constructed with glass-filled nylon or polyester housing (UL 94V-0 rated) and phosphor bronze or brass posts to ensure durability and reliable electrical contact. The posts are finished with gold flash over palladium-nickel plate (0.76 µm minimum on localized plate area), tin plate on solder-tail (2.54 µm minimum), and nickel underplate (1.27 µm minimum) for enhanced corrosion resistance and solderability. Key dimensional specifications include a post diameter of 0.64 ± 0.05 mm, solder tail length of 2.79 ± 0.25 mm, and overall housing length of 27.30 ± 0.51 mm. The connector is commonly used in instrumentation, data acquisition systems, and industrial control applications where secure latching and reliable signal integrity are essential.

Product Highlights:

  • Connector Type = Header - Pin
  • Header Type = Universal Ejection Pin Headers
  • AMP-LATCH Product Line
  • Standard Profile
  • 34 Positions

Search Keywords: 254992068

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-5499206-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
24
Package Type:
Tray
Type:
Ejector Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
34
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 454

Can Ship immediately

MOQ for In Stock Qty: 24

MOQ for out of Stock Qty: 72

Multiple: 24

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
24
$17.44
48
$17.40
72
$17.36
144
$10.68
216
$8.46
288 +
$8.28
Suppliers Standard Package
