Image is representational - see mfr. specs

2-794616-2

TE Connectivity / AMP Brand

FREE HANG DBL ROW HSG 22 POS ...

Datasheet

RoHS Compliant

Bag Packaging

Certificate of Compliance Guarantee

DESCRIPTION

2-794616-2 is a VDE-approved plug connector designed for the Micro MATE-N-LOK 3mm connector system, supporting 6 to 10 circuit positions in both single-row and dual-row configurations. The connector accommodates wire sizes from 22-18 AWG (0.3-0.9 mm²) with insulation diameters up to 2.79 mm, and is rated for a maximum current of 5 Amps per line at 250 Volts AC/DC. It features crimp and snap-in contact termination options with tin or gold plating (15 µm or 30 µm), and is compatible with standard receptacle housings (3-794617-x) and various terminal types. The connector operates reliably over a temperature range of -40°C to +105°C and is available in multiple configurations including free-hanging and panel-mount options, making it suitable for low-voltage lighting applications, automotive wiring, and industrial control systems requiring secure, reliable connections.

Product Highlights:

Housing
Housing Type = Plug
Accepts Contact Type = Pin
Number of Positions = 22
Number of Rows = 2

Potential Applications:

Search Keywords: 27946162

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

2-794616-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
