3-1393127-1 by te connectivity / amp brand

3-1393127-1

TE Connectivity / AMP Brand

PRD-11AY0-480=PRD ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PRD-11AY0-480 from TE Connectivity / P&B Brand is chassis mount double pole double throw (DPDT) power relay with 480VAC coil voltage and 4.5 kOhms coil resistance. This relay has 25A contact curent and 240VAC max switching voltage. Dimensions of this relay are: 85.73 mm x 63.8 mm x 63.5 mm. Operating temperature range is from -55°C to 45°C.

Product Highlights:

  • Relay Type = Heavy Duty, Power
  • Relay Style = Power
  • PRD Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 25 A

Search Keywords: 313931271

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1393127-1
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
480 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
25 A
Mounting:
N/A
Termination Style:
Screw Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 45 °C

IN STOCK: 2

Ships today, if you order in

On Order: 40   can ship 2/2/26

Factory Lead-Time 19 Weeks

Price (CAD)

Qty
Unit Price
1
$141.354
5
$121.554
10
$114.526
20
$106.088
40
$103.990
60 +
$98.601
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
