3-1827233-6 by te connectivity / amp brand

3-1827233-6

TE Connectivity / AMP Brand

Stacking Board Connector - Free Height - FSI Series - 440 Contacts - Plug - 0.5 mm - Surface Mount. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3-1827233-6 is a 440-way 4-row 0.5mm Free Height Vertical Plug with gold-plated copper alloy contacts and surface mount termination. This FH series connector comes with black high temperature thermoplastic housing and tin-plated solder tail, designed for parallel board to board stacking applications that require high density. The 0.5mm FH product is specified by the PICMG COM Express standard as the module to carrier card interface.

Product Highlights:

  • Plug
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 440
  • In-Line Contact Layout

Search Keywords: 318272336

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827233-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
18
Package Type:
Tray
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
PL
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
440
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C

IN STOCK: 348

Ships today, if you order in

Factory Lead-Time 2 Weeks

Price (CAD)

Qty
Unit Price
1
$72.691
5
$57.086
18
$55.632
36
$55.204
54
$54.774
108
$54.499
252 +
$54.223
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

3-1827231-6

.5FHR04H,440,B,GIG,08/Sn,HT,NS
