32056

Name: 32056
Brand: Te Connectivity Amp Brand
SKU: 10358657
Price: 28.56 USD
Availability: InStock

TERMINAL,PIDG SPD 16-14 8 ...

View Datasheet Ask the Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

32056 is a PIDG terminal splice designed for electrical connections in industrial applications. It accommodates 14-10 AWG wire sizes and features an M4 stud connection with a width of 0.385 inches (9.78 mm) and length of 0.908 inches (23.06 mm). The terminal is constructed from high-conductivity copper with tin plating for corrosion protection, and includes a copper sleeve for vibration resistance and improved wire insulation support. The body incorporates inner serrations for maximum electrical contact and tensile strength. It operates at a maximum voltage of 300V and temperature of 105°C, making it suitable for instruments, lighting, power supplies, motors, and aerospace applications. The product is UL/CSA listed and Mil-Spec approved for reliable performance in demanding industrial environments.

Product Highlights:

Terminal Shape = Spade Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 32056

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

32056

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
