324159 by te connectivity / amp brand

324159

TE Connectivity / AMP Brand

TERM, RING, PIDG, 16-14, #4 ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / AMP Brand part 324159 is a high-quality terminal designed for efficient electrical connections. With its reliable performance and durable construction, this terminal is ideal for a wide range of applications. It is a ring terminal specifically designed for use with wire sizes ranging from 16 to 14 AWG and can accommodate up to #4 stud sizes. This terminal is part of the PIDG series, which ensures excellent conductivity, optimal mechanical performance, and reliable insulation. For secure and efficient electrical connections, look no further than TE Connectivity / AMP Brand part 324159.

Product Highlights:

  • Terminal Shape = Ring Tongue
  • Receptacle Style = Straight
  • Body Style = PIDG
  • Barrel Type = Closed Barrel
  • Wire/Cable Type = Regular Wire

Search Keywords: 324159

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
324159
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Box
Type:
PIDG Ring Tongue Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
2.84 mm
Dimension:
17.86 x 6.35 mm
Wire Size:
14-16 AWG
Color:
Blue
Operating Temperature:
N/A

IN STOCK: 7,476

Can Ship immediately

Minimum Order: 50

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
50
$0.4957
500
$0.3511
1,000
$0.3339
3,000
$0.3165
5,000
$0.3120
8,000
$0.3104
15,000
$0.3089
25,000 +
$0.3074
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Product Changes

Accessories

47387

Crimp Tool - Ratchet - PIDG / PLASTI-GRIP - 20-14AWG - Terminals and Splices - CERTI-CRIMP ...

58433-3

Crimp Tool: PRO-CRIMPER III Mnl Crimp Tool Frame (354940-1) + Die Set for PIDG, PLASTI-GRI ...

58423-1

Tool Die Set For Splices and Terminals - 10 to 22 AWG.

169404

CERTI-LOK DIE

Show 2 More
