344267-1 by te connectivity / amp brand
Image is representational - see mfr. specs

344267-1

TE Connectivity / AMP Brand

6 WAY REC. HSG. SIL. SEALECONO ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 344267-1 is a sealed Econoseal III 6-way receptacle connector housing designed for wire-to-wire power transmission in automotive applications. It features a 3×2 configuration with crimp termination for discrete stranded wire, supporting wire sizes from 14 to 20 AWG (0.5 to 2 mm²) with a rated current capacity of 10 A at 12 VDC. The housing is constructed from black nylon with an orange silicone rubber peripheral seal, providing IP6/IP4 dust and water sealing protection and operating reliably across -40°C to +105°C. The connector incorporates latching mating retention with polarization alignment, a 4.80 mm centerline spacing, and dimensions of 27.60 × 25.40 × 26.20 mm, making it suitable for sealed automotive electrical systems requiring robust environmental protection and reliable power distribution.

Product Highlights:

  • Housing
  • Housing Type = Receptacle
  • Color = Black
  • Number of Positions = 6
  • Terminate To Wire

Search Keywords: 3442671

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
344267-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
HU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Bag
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
6
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A

IN STOCK: 900

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
10
$2.785
100
$2.383
250
$2.191
500
$2.087
1,000
$1.950
2,500
$1.862
5,000
$1.853
7,500 +
$1.844
Suppliers Standard Package
