350547-3 by te connectivity / amp brand
Image is representational - see mfr. specs

350547-3

TE Connectivity / AMP Brand

UMNL PIN 20-14 PTPPHBZ L/P ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

350547-3 is a phosphor bronze pre-tinned loose piece contact designed for 5.0 mm Power Key Connectors (5.0 PKC) wire-to-board applications. This contact is specifically engineered for wire sizes 20-14 AWG (5.2-10 mm²) with an insulation diameter range of 0.060-0.130 inches (1.52-3.30 mm). The contact features a pin length dimension of 0.790 inches (20.06 mm) and is constructed from phosphor bronze material with pre-tin finish, providing excellent corrosion resistance and reliable electrical performance. The contact is compatible with duplex-style connectors and is used in power circuit applications, particularly for home appliances and gas appliances where robust, reliable connections are essential. This loose piece contact is suitable for both manual assembly and automated crimping processes using compatible HDM applicators.

Product Highlights:

  • Contact
  • Universal MATE-N-LOK
  • Not CompactPCI
  • Contact Type = Pin
  • Wire Range = 0.50-2.00² [20-14] mm [AWG]

Search Keywords: 3505473

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
350547-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Power
Gender:
Pin
Contact Size:
N/A
Wire Size:
14-20 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Pre-Tin
Maximum Current Rating:
19 A
Termination Method:
Crimp
  Different packaging options available.  See Alternatives

IN STOCK: 9,465

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.1568
3,000
$0.1339
5,000
$0.1306
8,000
$0.1279
25,000
$0.1257
50,000
$0.1236
100,000 +
$0.1213
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes

Accessories

91500-1

Hand Crimper Tool For Rectangular Contacts - 14 to 20 AWG - Ratchet - Side Entry.

90546-1

Pro-Crimper III Hand Crimping Tool Assembly With Die - 20 to 14 AWG - For Rectangular Cont ...

90546-2

PROCRIMPER DIE ASSY UNIV MNL

1804030-1

Extraction Tool For Universal Mate-N-Lok, Universal Mate-N-LokII - 60 g.

455830-1

Insertion Tool for Universal MATE-N-LOK; Commercial MATE-N-LOK; Mini-Universal MATE-N-LOK
