3-521057-2 by te connectivity / amp brand
Image is representational - see mfr. specs

3-521057-2

TE Connectivity / AMP Brand

ULTRAFAST 250 ASSY TAB 16-14 AWG TPBR ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

3-521057-2 is an Ultra-Fast Plus fully insulated FASTON tab terminal designed for quick-connect electrical connections. This .250 series terminal accommodates 16-14 AWG wire with an insulation diameter range of 0.090-0.160 inches (2.29-4.06 mm) and features brass base material with tin plating. Key dimensions include A: 0.290 inches (7.37 mm), B: 0.522 inches (13.26 mm), C: 0.230 inches (5.84 mm), and D: 0.855 inches (21.72 mm), with a mating tab size of 0.032 x 0.250 inches (0.81 x 6.35 mm). The terminal features a nylon housing rated UL 94 V-2 for flammability, color-coded blue for 16-14 AWG identification, and is UL rated at +105°C. These terminals are ideal for applications requiring reliable, insulated quick-connect solutions with shock and short hazard prevention.

Product Highlights:

  • Tab
  • Proprietary Name = Ultra-Fast Plus
  • Tab Fit = 6.35 x 0.81 mm
  • Brass Material
  • Insulation Diameter = 2.29-4.06 [.090-.160] mm [in]

Search Keywords: 35210572

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-521057-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
1400
Package Type:
Reel
Type:
Quick Disconnect Terminal
Gender:
M
Tab Size:
5.14 mm²
Stud Size:
N/A
Wire Size:
14-16 AWG
Color:
Blue
Operating Temperature:
105(Max) °C

IN STOCK: 36,400

Ships today, if you order in

Manufacturer Stock: 39,200   can ship 5/25/26

Minimum Order Quantity: 1400

Multiple: 1400

Factory Lead-Time 6 Weeks can ship 6/24/26

Price (USD)

Qty
Unit Price
1,400
$0.2374
2,800
$0.2351
5,600
$0.2345
8,400
$0.2340
11,200
$0.2334
15,400
$0.2328
25,200
$0.2323
50,400 +
$0.2316
Reel Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
