Image is representational - see mfr. specs

35362

Name: 35362
Brand: Te Connectivity Amp Brand
SKU: 10362263
Price: 58.75 USD
Availability: InStock

TE Connectivity / AMP Brand

TERMINAL,PIDG R 16-14HD 1/4 ...

Datasheet

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 35362 is a pre-insulated solderless terminal designed for reliable wire termination in control circuits and power wiring applications. It accommodates 16-14 AWG wire (2.050–5.180 circular mils, 1.04–2.62 mm²) and features a 1/4" M6 stud connection with yellow/black insulation color coding for easy identification. The terminal has a tongue material thickness of 0.050" (1.27 mm) and dimensions of W: 0.531" (13.49 mm), C: 0.437" (11.10 mm), E: 1.17" (28.37 mm), and L: 1.385" (35.18 mm). The wire insulation diameter maximum is 0.300" (7.62 mm). The terminal incorporates serrations inside the barrel for exceptional contact and tensile strength, nylon insulation providing high dielectric strength, and a funnel entry design for easy wire insertion during high-speed production. It is UL, CSA, and Military approved, making it suitable for demanding industrial, automotive, and aerospace applications requiring uniform, high-quality terminations.

Product Highlights:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 35362

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

35362

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
