3-641215-5 by te connectivity / amp brand

3-641215-5

TE Connectivity / AMP Brand

Connector Header Through Hole 5 position 0.100" (2.54mm) ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MTA-100 series MTA Connector System is a wire-to-board and wire-to-wire system based on insulation displacement contact (IDC) technology. Mass termination of wires provides the lowest applied cost because it drastically reduces the labour content of virtually any cable or harness assembly required. MTA 100 connectors have contacts in a single row on 0.100-inch (2.54mm) centre. The design features wire feed-through capability for daisy-chain applications. Insulation displacement contacts (IDC) are used to terminate a wide range of conductor sizes. Header assemblies for board mount applications include right-angle and vertical mount products available in through-hole and surface mount configurations. Colour coded housing for wire gage Tin, 15 and 30 gold plating options Audible latch for wire-to-wire (posted) housings Terminates 28 to 22AWG discrete wire or notched ribbon cable 2 to 28 Positions ad shrouded headers 2 to 14 available 250V and 5A Rating Applications Industrial

Product Highlights:

  • 5 Positions
  • With Contacts
  • Housing Gender = Header - Pin
  • Contact Gender = Pin
  • MTA-100 Product Line

Search Keywords: 36412155

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-641215-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Type:
Wire to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
5
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
5/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,942

Ships today, if you order in

Minimum Order: 25

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
25
$1.175
250
$0.840
500
$0.784
1,000
$0.758
2,500
$0.748
5,000
$0.744
7,500
$0.740
10,000 +
$0.736
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

641237-5

Conn IDC Connector F 5 POS 2.54mm IDT RA Cable Mount Bag

3-641237-5

05P MTA100 CONN ASSY RED 30AU

641238-5

Conn IDC Connector F 5 POS 2.54mm IDT RA Cable Mount Loose Piece

3-641238-5

05P MTA100 CONN ASSY NATL 30AU

641239-5

05P MTA100 CONN ASSY BLU 30AU

3-641239-5

05P MTA100 CONN ASSY BLU LF

3-641240-5

05P MTA100 CONN ASSY GRN LF

3-644020-5

05P MTA100 CONN ASSY 30AU

644020-5

MTA 100 CONNECTOR ASSEMBLY, 24 AWG, STANDARD

644042-5

05P MTA100 CONN ASSY 30AU

1375820-5

CST-100 II HOUSING 5 POS

3-644042-5

05P MTA100 CONN ASSY LF

3-644043-5

05P MTA100 CONN ASSY LF

3-644702-5

05P MTA100 CONN ASSY F/T LF

644043-5

MTA, CST-100 II, MT-6 and SL Connectors and Headers

Show 13 More
