3-644893-6 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

3-644893-6

06P CST100 SHRD HDR ASSY LF ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / AMP BRAND part 3-644893-6 is a 06P CST100 SHRD HDR ASSY LF connector assembly. This high-quality connector features a compact size and is designed for easy installation. Perfect for a variety of applications, this connector ensures reliable and secure connections.

Search Keywords: 36448936

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-644893-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
PCB Mount Alignment:
With
Operating Voltage:
250 VAC
Connector System:
Wire-to-Board
Mating Retention Type:
Friction Lock
Housing Material:
Polyester - GF
PCB Mount Orientation:
Vertical
PCB Contact Termination Area Plating Material Thickness:
150 – 250 µin, 3.81 – 6.35 µm
Termination Method to Printed Circuit Board:
Through Hole - Solder
Contact Mating Area Plating Material:
Tin
Termination Post & Tail Length:
.14 in, 3.56 mm
Contact Underplating Material:
Nickel
Agency/Standard:
CSA , UL
Mating Square Post Dimension:
.025 in, .64 mm
Mating Retention:
With
Number of Rows:
1
PCB Thickness (Recommended):
.063 in, 1.6 mm
PCB Connector Assembly Type:
PCB Mount Header
PCB Mount Retention Type:
Tab
Contact Shape & Form:
Square
Contact Type:
Pin
Contact Base Material:
Copper Alloy
Mating Alignment Type:
Polarization
Circuit Application:
Signal
Contact Current Rating (Max):
4 A
Connector & Contact Terminates To:
Printed Circuit Board
UL Flammability Rating:
UL 94V-0
Connector Height:
.41 in, 10.41 mm
Number of Positions:
6
Contact Underplating Material Thickness:
50 µin, 1.27 µm
Contact Mating Area Plating Material Thickness:
150 – 250 µin, 3.81 – 6.35 µm
Connector Length:
.784 in, 19.91 mm
PCB Contact Termination Area Plating Material:
Tin
PCB Mount Retention:
With
Centerline (Pitch):
.1 in, 2.54 mm
Mating Alignment:
With
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
PCB Mount Alignment Type:
Peg
Contact Mating Area Length:
.28 in, 7.11 mm
Square Termination Post & Tail Dimension:
.025 in, .64 mm
Connector Mounting Type:
Board Mount
Packaging Quantity:
1
Contact Layout:
Inline
Panel Mount Feature:
Without
PCB Contact Termination Area Plating Material Finish:
Matte
Sealable:
No
Contact Mating Area Plating Material Finish:
Bright
Packaging Type:
Package
Approved Standards:
CSA LR7189 , UL E28476
Primary Product Color:
Black
Header Type:
Fully Shrouded

IN STOCK: 4,343

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 1375

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
25
$1.83
250
$1.53
500
$1.40
1,000
$1.25
1,375
$1.16
2,750
$1.08
4,125
$1.06
5,500 +
$1.04
