388632-2 by te connectivity / amp brand
Image is representational - see mfr. specs

388632-2

TE Connectivity / AMP Brand

PLATE-SHEAR-FRONT ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

388632-2 is a crimp tooling component used in wire termination processes to achieve precise wire-barrel compression and connection. The tooling is designed to maintain critical dimensional parameters including crimp height (CH) and crimp width (CW) to achieve an optimal Area Index (AI) of approximately 80%, which directly impacts connection quality and pull test performance. Key design specifications include a nominal crimp height of 0.073 inches, crimp width of 0.110 inches, crimper leg taper of 3.0 degrees, and anvil width of 0.109 inches with a nominal anvil-to-crimper clearance of 0.005 inches. The tooling components are manufactured from materials selected to withstand high loads, moderate shock, and the aggressive shear loading generated during the plastic deformation and extrusion of terminal barrels. This crimp tooling is essential for maintaining production quality metrics such as crimp symmetry, lead throughput, and consistent termination performance in high-volume connector assembly operations.

Search Keywords: 3886322

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
388632-2
Unit of Measure:
Per Each
RoHS:
No
HTS:
8466944000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack

IN STOCK: 2

Ships today, if you order in

Manufacturer Stock: 58   can ship 5/25/26

Factory Lead-Time 8 Weeks can ship 7/8/26

Price (USD)

Qty
Unit Price
1
$799.38
3
$774.14
5 +
$708.66
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
