4-1618388-6 by te connectivity / amp brand

4-1618388-6

TE Connectivity / AMP Brand

RELAY CONTACTOR SPST 500A 24V ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4-1618388-6 is a 1-pole Contactor with DC coil. 1 form-A (SPST-NO) contact configuration. Studs, #10-32 threaded (Electrical connection is made to the tab at the base of the stud). Bottom mount and male 10mm x M8 threaded terminals. Designed to be the lowest cost sealed contactor in the industry with its current rating (500+A carry, 2000A interrupt at 320VDC). Hermetically sealed intrinsically safe, operates in explosive/harsh environments with no oxidation or contamination of coils or contacts, including long periods of non-operation. Typical applications include battery switching and backup, DC voltage power control, circuit protection and safety. Designed and built in accordance to AIAG QS9000. Designed and built in accordance to AIAG QS9000 High voltage DC contactor Versatile coil/power connection Harsh Environment and Mil Spec compatible Applications Industrial, Power Management, Automation & Process Control, Automotive, Safety

Product Highlights:

  • Contactor Type = Sealed
  • LEV200 Series
  • DC Actuating System
  • Number of Poles = 1
  • Contact Arrangement = 1 Form A, SPST-NO

Search Keywords: 416183886

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
4-1618388-6
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Maximum Current Rating:
500 A
Contact Arrangement:
SPST-NO
DC Coil Voltage:
24 V
AC Coil Voltage:
N/A
Maximum DC Voltage Rating:
N/A
Maximum AC Voltage Rating:
N/A
Termination Style:
Screw Terminal
Led Indicator:
No
Mounting:
Flange Mount

IN STOCK: 700

Ships today, if you order in

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
1
$90.722
5
$86.963
10
$84.264
15
$83.430
25
$82.101
50 +
$80.052
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
