4-2103015-4

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

4-2103015-4

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

MX

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Package Type:

Pack

Polarized:

Yes

Primary Product Color:

Orange

Height:

1.087 in, 27.6 mm

Connector & Housing Type:

Housing for female terminals

Primary Locking Feature:

On the Terminal

UL Flammability Rating:

UL 94-HB

Cable Exit Angle:

180 °

Sealable:

Yes

Nominal Voltage Architecture:

12 V, 125 V, 24 V, 240 V, 42 V, 48 V, 500 V, 550 V, 600 V, 80 V

Connector System:

Wire-to-Board , Wire-to-Device

Connector Position Assurance Capable:

Yes

Degree of Protection:

IP6K9K

Length:

1.295 in, 32.9 mm

Operating Voltage:

850 VDC

Centerline (Pitch):

.409 in, 10.4 mm

Strain Relief:

Yes

Body Material:

PA GF

Circuit Application:

Signal

Serviceable:

Yes

Terminal Position Assurance:

No

Operating Temperature Range:

-40 – 125 °C, -40 – 257 °F

Width:

2.177 in, 55.3 mm

Mounting Feature:

Without

Operating Temperature (Max):

100 °C, 105 °C, 110 °C, 120 °C, 125 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C

Number of Positions:

2

Mating Tab Width:

.11 in, 2.8 mm

Hybrid Connector:

No

Number of Rows:

1
