493577-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

493577-2

ASSY 10 WAY JPT REC ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / AMP Brand part 493577-2 is a 10-way JPT receptacle assembly. This component is designed for easy connectivity and reliable performance in a variety of applications. Trust TE Connectivity for high-quality, precision-engineered parts that meet the demands of your project.

Product Highlights:

  • Connector
  • Housing
  • Housing Gender = Receptacle
  • Not Preloaded
  • Contact Gender = Receptacle

Search Keywords: 4935772

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
493577-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
BR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
336
Package Type:
BOX
Cable Exit Angle:
180 °
Primary Product Color:
Black
Number of Rows:
2
Sealable:
Yes
Serviceable:
Yes
Width:
1.299 in, 33 mm
Mating Tab Width:
.11 in, 2.8 mm
Number of Positions:
10
Hybrid Connector:
No
Strain Relief:
No
Mounting Feature:
Without
Packaging Method:
Box
Terminal Position Assurance:
Yes
Operating Voltage:
12 VDC
Circuit Application:
Signal
Connector System:
Wire-to-Board , Wire-to-Device
Operating Temperature Range:
-40 – 130 °C, -40 – 266 °F
Primary Locking Feature:
On the Terminal
Body Material:
PBT
Operating Temperature (Max):
100 °C, 105 °C, 110 °C, 120 °C, 125 °C, 130 °C, 70 °C, 75 °C, 80 °C, 85 °C
Height:
1.13 in, 28.7 mm
Polarized:
Yes
UL Flammability Rating:
UL 94-HB
Connector & Housing Type:
Housing for female terminals
Connector Position Assurance Capable:
No
Nominal Voltage Architecture:
12 V
Centerline (Pitch):
.236 in, 6 mm
Row-to-Row Spacing:
.236 in, 6 mm
Length:
.185 in, 47.1 mm

IN STOCK: 0

On Order: 3,360   can ship 11/4/26

Minimum Order Quantity: 25

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$2.08
100
$1.88
336
$1.70
672
$1.69
1,008
$1.58
2,688
$1.52
5,040
$1.51
7,728 +
$1.50
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
