50846

TE Connectivity / AMP Brand

TERMINAL,PIDG PTFE R 12-10 1/4 ...

Datasheet

RoHS Compliant

Box Packaging

Discontinued

DESCRIPTION

50846 is a STRATO-THERM pre-insulated ring tongue terminal designed for high temperature electrical connections up to 550°F (288°C). This terminal accommodates 12-10 AWG wire sizes (5,180-13,100 circular mils) and features a 5/16 (M8) stud size with nickel-plated copper body construction per ASTM B152. The terminal features TEFLON insulation with black color coding, a tongue material thickness of 0.042 inches (1.07 mm), and maximum dimensions of W: 0.531 inches (13.49 mm), C Min: 0.437 inches (11.10 mm), E Max: 1.012 inches (25.70 mm), and L Max: 1.280 inches (32.51 mm). Ideal for aerospace, industrial, and automotive applications where extreme heat, vibration, and corrosion resistance are critical requirements.

Product Highlights:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG, STRATO-THERM
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 50846

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

50846

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
