5100143-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5100143-1

TE Connectivity / AMP Brand

2MM H.M. TYPE "A" PIN ASSY. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5100143-1 is a 2mm Hard Metric PCB mount connector plug assembly designed for board-to-board interconnection applications. It features a Type A configuration with 110 positions distributed across 5 rows (A, B, C, D, E), providing multi-purpose center mating polarization for reliable signal routing. The connector is vertically mounted with a module length of 50.00 mm and employs gold-plated (30 µm) mating contacts on a phosphor bronze base with short tail contact style, ensuring excellent electrical performance and durability. The housing is constructed from PBT-GF (polybutyrene terephthalate glass-filled) material in gray with UL 94V-0 flammability rating, and termination is accomplished via tin over nickel plating on the 2mm HM interface. This connector is RoHS and ELV compliant, making it suitable for industrial backplane and midplane applications requiring robust, high-density interconnection solutions.

Product Highlights:

  • Connector
  • Connector Type = Type A
  • Plug
  • Interface Type = 2mm HM
  • Contact Type = ACTION PIN Post, Signal

Search Keywords: 51001431

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5100143-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
Tube
Type:
Hard Metric
Gender:
PL
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2 mm
Number of Contacts:
110
Termination Method:
PRESS FIT
Operating Temperature:
-55 to 125 °C

IN STOCK: 410

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
10
$6.276
30
$4.716
100
$4.595
250
$4.492
500
$4.286
1,000
$4.040
2,500
$3.909
5,000 +
$3.804
Suppliers Standard Package
