5100147-1 by te connectivity / amp brand

5100147-1

TE Connectivity / AMP Brand

Backplane Connector - Receptacle - Female Sockets - 110 Position - 5 Rows - 0.079" (2.00mm) Pitch - Press-Fit - Board Edge, Through Hole, Right Angle. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5100147-1 from TE Connectivity / AMP Brand is board edge, through hole mounting, right angle backplane connector Z-PACK series, receptacle with female sockets, 110 positions, 5 rows, 0.079" (2.00mm) pitch and press-fit termination. Operating temperature range is from -55 to 125 °C ( -67 to 257 °F ).

Product Highlights:

  • Connector
  • Connector Type = Type A
  • Receptacle
  • Interface Type = 2mm HM
  • Contact Type = Signal

Search Keywords: 51001471

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5100147-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
11
Package Type:
Tube
Type:
Hard Metric
Gender:
RCP
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2 mm
Number of Contacts:
110
Termination Method:
PRESS FIT
Operating Temperature:
-55 to 125 °C

IN STOCK: 7,206

Can Ship immediately

Minimum Order: 11

Multiple: 11

Factory Lead-Time 7 Weeks

Price (CAD)

Qty
Unit Price
1
$13.257
11
$12.051
33
$10.490
55
$10.153
110
$9.953
253
$9.785
506
$9.662
1,001 +
$9.616
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
