5103311-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5103311-1

TE Connectivity / AMP Brand

A/L LOW PRO HDR 10P RA BLACK ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5103311-1 is a low-profile pin header connector designed for wire-to-board applications in ribbon cable interconnect systems. This 10-position header features a 0.100" [2.54 mm] centerline spacing and is configured with nickel post plating (Plating A specification). The connector has a solderail length of 0.110" [2.79 mm] and dimensions of 0.800" [20.32 mm] (A) by 0.400" [10.16 mm] (B), with recommended PCB hole layout for manual insertion. The product is RoHS compliant and is commonly used in equipment for board-to-board or subsystem-to-subsystem connections, providing reliable mass termination capabilities for up to 10 conductors simultaneously without requiring cable stripping or pre-preparation.

Product Highlights:

  • Connector Type = Pin Headers
  • Low Profile
  • Number of Positions = 10
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Right Angle

Search Keywords: 51033111

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5103311-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
125
Package Type:
Tube
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 765

Ships today, if you order in

Minimum Order Quantity: 125

Multiple: 125

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
125
$1.460
250
$1.404
500
$1.266
1,000
$1.246
2,500
$1.236
5,000
$1.196
7,500
$1.156
10,000 +
$1.149
Suppliers Standard Package
