5-1634537-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5-1634537-1

TE Connectivity / AMP Brand

F Type Elbow Adaptor Plug - Jack ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5-1634537-1 is an F Series right-angle PC board mount RF coaxial jack connector designed for high temperature applications. This connector features PTFE dielectric material throughout (bottom, middle, and front sections) for enhanced thermal performance and is suitable for pin in paste reflow and high temperature processing. The body plating consists of nickel barrel with tin base, and the center contact is tin plated. The connector accepts center conductor diameters and is designed for PCB termination with a recommended panel cutout diameter of 9.65 mm. Common applications include RF signal transmission in telecommunications, cable systems, and broadcast equipment where reliable high-frequency connections are required.

Product Highlights:

  • Adapter
  • Connector Type = F Series
  • Adapter Style = Right-Angle
  • Adapter Type = Jack-Plug
  • Brass Center Contact Material

Search Keywords: 516345371

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-1634537-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Type:
Type F Adapter
Impedance:
N/A
Operating Frequency:
N/A
Gender:
RCP/PL
Mounting:
N/A
Body Orientation:
Right Angle
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
18 x 11 x 25.8 mm

IN STOCK: 729

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 250

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
10
$4.160
50
$3.706
100
$3.497
250
$3.254
500
$3.084
750
$3.076
1,000 +
$2.845
