51863-1
TE Connectivity / AMP BrandRing Terminal Connector 6 Stud Circular 16-22 AWG Crimp ...
DESCRIPTION
The PIDG series Fork/Spade Tongue Terminal designed for uniform reliability in the most difficult circuit environments. They consist of a tin-plated copper or tin-plated phosphor bronze body for spring spades, plus a copper and coloured insulation sleeve fitted over a terminal barrel. The specialized design of tool dies and the construction of the terminal allows for uniform insulation thickness under crimping pressure, transmitting this pressure evenly to the centre of the crimping area. The body has serrations for maximum contact and tensile strength. The insulation sleeves and the corresponding tooling are colour-coded by wire-size for easier identification. PIDG terminals have copper sleeve for improved wire insulation support Specific tooling dedicated for different volumes or circumstances is available Applications Sensing & Instrumentation, Lighting, Power Management, Logistics, Motor Drive & Control, Defence, Military & Aerospace, Consumer Electronics
Product Highlights:
- Terminal Shape = Ring Tongue
- Receptacle Style = Straight
- Body Style = PIDG
- Barrel Type = Closed Barrel
- Wire/Cable Type = Regular Wire
Search Keywords: 518631
SPECIFICATIONS
IN STOCK: 36,425
Ships today, if you order in
On Order:
45,000
can ship 12/1/25
Minimum Order: 5000
Multiple: 5000
Factory Lead-Time 30 Weeks
3D PDF
Product Drawing - TERMINAL, RING TONGUE, PIDG WIRE SIZE: 22-16 AWG
Datasheet
Product Specification - Pre-Insulated Diamond Grip (PIDG) Terminals, Splices, and End Caps
