5222006-1 by te connectivity / amp brand

5222006-1

TE Connectivity / AMP Brand

RF / Coaxial Connector - BNC Coaxial - Straight Jack - Through Hole Vertical - 50 ohm - Beryllium Copper. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5222006-1 is an action/compliant tail BNC Straight Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated beryllium copper centre contact and a PTFE insulator.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Vertical

Search Keywords: 52220061

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5222006-1
RoHS:
Yes
HTS:
8536694010
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Tray
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
N/A
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
PRESS FIT
Operating Temperature:
N/A
Dimension:
20.57 x 11.94 mm

IN STOCK: 1,650

Ships today, if you order in

Manufacturer Stock: 3,000   can ship 12/5/25

Minimum Order: 5

Factory Lead-Time 8 Weeks can ship 1/15/26

Price (USD)

Qty
Unit Price
5
$5.953
25
$4.110
100
$4.007
300
$3.955
500
$3.904
1,000
$3.883
2,500
$3.863
5,000 +
$3.821
Suppliers Standard Package
