5226978-3 by te connectivity / amp brand

5226978-3

TE Connectivity / AMP Brand

RTANG JK W/FLANGES, BNC PCB ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Part number 5226978-3 is a RTANG JK W/FLANGES, BNC PCB connector by TE Connectivity / AMP Brand. This high-quality connector is designed for use in printed circuit boards and features a BNC interface, making it ideal for applications requiring reliable signal transmission. The compact size and included flanges ensure easy installation and secure attachment. Trust TE Connectivity / AMP Brand for durable and efficient connectivity solutions.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Right Angle

Search Keywords: 52269783

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5226978-3
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
N/A
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
29.21 x 35.56 x 15.88 mm

IN STOCK: 68

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 64

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$10.877
10
$7.818
25
$7.777
50
$7.704
64
$7.663
128
$7.622
192
$7.581
255 +
$7.550
